LGA1700/ 1800 1U, Copper (D17U series)
D17U series
(for LGA1700/ LGA1800 1U)
D17U stands for Ultra-slim designed solutions in REGO coolers for Intel LGA1700/ 1800 Alder Lake-S CPU series and indicated to our RGD31xx families.
[Meets]
1U Copper CPU Coolers, TDP: 35 to 65 Watts
[Features & Benefits]
High quality, high reliability, lower noise level, long term supply, customization available
>> Target Market <<
AI Edge Computing
Server Based IPC
Gaming mini PC
Industrial Box PC
Embedded Boards
Medical AIO PC
![](/ezfiles/925/1925/img/3203/l1-2.jpg)
![](/ezfiles/925/1925/img/3203/l2-2.jpg)
![](/ezfiles/925/1925/img/3203/l3-2.jpg)
- Lower Noise Level
- Long term supply
- Fast samples
- Semi-customization available
- Long term supply
- Fast samples
- Semi-customization available
Part Number | RGD3118-004 | RGD3114(Z)-002 | RGD3124AF1-BF(Z)-002 |
CPU Socket | Intel Desktop LGA1700 35-65W | Intel Desktop LGA1700 / 65W | Intel Desktop LGA1700 65W |
Outline Dimension (mm) | 90 x 90 x 15 | 90 x 90 x 22.5 | 90 x 90 x 27.5 |
Rth (℃/W) | 0.409 | 0.463 | 0.283 |
Fan Spec | 70x70x10mm 4way 4800 RPM 43dB(A) |
70x70x10mm 4way 5500 RPM 46dB(A) |
80x80x15mm 4way 6600 RPM 64dB(A) |
Heat Sink Material | Copper Stacked Fin | Copper Stacked Fin | Copper Stacked Fin |
